«Kyiv Crane Machinery Plant LLC» together with PodemCrane AD (Bulgaria) produces bridge double-girder cranes for:
- machine-building enterprises;
- chemical industry enterprises;
- mining and processing complexes;
- ore mining and processing enterprises;
- metallurgical plants and foundries;
- workshops for the production of metal structures;
- warehouses of finished products.
Types of bridge cranes
Depending on the design features, we produce the following types of bridge cranes: single-beam and double-beam, suspension and supporting, with electric or manual drive, hook, clamshell and special. For the transport of explosive goods and work in potentially explosive areas, it is possible to order an explosion-proof version.
The main technical characteristics of a bridge double-girder crane
The lifting capacity of the crane can reach up to 100.0 tons. The distance between the crane rails (span) is up to 40.0 m. The lifting height of the cargo is up to 50.0 m, the speed of the bridge is 20.0-120.0 m / min, the speed of the freight trolley is 10.0-60.0 m / min, the speed of lifting the load is 1.5-30.0 m / min.
Depending on the wishes of the customer, the control of the double-girder overhead crane can be carried out both from the cabin and from the floor (via a suspended console or via a radio control system). Operation of the crane is possible at temperatures from -40 ° C to + 70 ° C in operating modes:
- А1-А3 (1Ам by FEM) - easy;
A5 (2m by FEM) - medium;
A6-A7 (3m by FEM) - heavy;
A8 (4m by FEM) - very heavy.
The complete set of overhead crane manufactured by the «Kyiv Crane Machinery Plant LLC» includes:
- crane trolley type telescopic type produced by PodemCrane AD (Bulgaria) or deployed with the use of geared motors SEW-Eurodrive (Germany);
- end girders type G produced by PodemCrane AD (Bulgaria);
- span bridge: beams of welded box-type construction, steel 09G2S;
- motor-reducers of movement of manufacture PodemCrane or SEW-Eurodrive (Germany);
- electrical equipment Schneider Electric (France);
- current lead of Festoon type;
- frequency drive of lifting and movement of Schneider Electric type Altivar;
- by agreement: control of the crane from the floor or from the cabin;
- stationary or mobile control cabin, equipped with convector and air conditioning, arm-chair with 3-5-position control joysticks;
- safety devices: trailer and crane travel limit switches, alarm and audible warning system during operation, parameter recorder, load limiter.
In the complete set of overhead cranes we use only high-quality components of production of the world's leading leaders in their industries - this ensures the reliability and durability of our crane equipment.
All products comply with European standards:
- Machinery Directive 2006/42/EC (Директива 2006/42/ЕС о безопасности машин и оборудования)
- DIN EN ISO12100: "Safety of machines. Basic terms, general principles of design" (Стандарт EN ISO 12100 Безопасность машин и механизмов)
- EN60204-1: "Safety of machines. Electrical equipment of machines" (EN 60204: Безопасность машин. Электрооборудование машин)
Specialists of the «Kyiv Crane Machinery Plant LLC» provide a full range of works from the design phase to commissioning the crane and conducting maintenance.
Works on installation and commissioning are carried out on the basis of the Permit to carry out works of increased danger №4114.12.32.
Here you can buy a bridge with a double-girder crane with a deferred payment or take it to lease. Flexible payment system will allow to operate the crane and pay the cost according to the agreed individual schedule.
The price for a bridge crane is formed depending on the configuration of the crane according to your technical requirements. For the selection of the optimal technical solution and preparation of the technical and commercial proposal, please fill out the questionnaire.
